Wire harness workbench accessories
Different types of holders, retainers, corner posts and wire breakout systems which help to hold wires and form bundles on wire harness workbench.
They can be placed anywhere on wire harness worktop and attached to it through a special horizontal perforation (13×6 mm) by 3,5×16 screws.
- Options selection
|
Code
|
Description |
Dimensions (WхHхD) |
Max. Bundle Diameter |
Comments |
|
RER.75-S6-X |
Harness elastic retainer |
30х56,1х28,4 mm |
19 mm |
Cable bundles are formed as cable bundles are inserted. Completed bundles can be easily removed |
|
RER.75E-X |
Harness replacement elastic band for RER.75-S6-X |
|
|
The elastic band is replaceable |
|
RER2.0-S6-X |
Harness elastic retainer |
33,3х100,2х71,4 mm |
50,8 mm |
Cable bundles are formed as cable bundles are inserted. Completed bundles can be easily removed |
|
RER2.0E-X |
Harness replacement elastic band for RER2.0-S6-X |
|
|
The elastic band is replaceable |
|
ER.5-E4-X |
Low profile elastic retainer |
49,8х25,4х14,2 mm |
12,7 mm |
Cable bundles are formed as cable bundles are inserted. Completed bundles can be easily removed
|
|
ER1.25-E4-X |
Low profile elastic retainer |
73,7х50,8х24,1 mm |
31,8 mm |
Cable bundles are formed as cable bundles are inserted. Completed bundles can be easily removed |
|
CPH.75-S8-X |
High profile corner post |
22,9х47,8х40,8 mm |
19 mm |
Designed to pre-form tight bundles at harness corners and breakouts. Top arm rotates upward for easy removal of completed harness |
|
CPL.75-S8-X |
Low profile corner post |
22,4х27,4х38,6 mm |
19 mm |
Designed to pre-form tight bundles at harness corners and breakouts. Top arm rotates upward for easy removal of completed harness |
Harness board spring and spring holder holds wire ends secure while harness is being fabricated. Wires simply pull out from spring when harness is removed
|
Code |
Description |
Span between fastenings (length) |
|
|
SHH3-S8-X |
Linkage for wire breakout system |
172,7 mm |
|
|
PBSC6-X |
Spring wire breakout system, should be mounted to linkage |
152,4 mm |
